11-14 120 Series Maternal/Fetal Monitor Revision B
2015590-001
Peripheral Devices: Model 115-Compatible Communications Protocols
Table 11-3. Heart Rate Modes
Hr1 Mode Hr2 Mode Ascii Character Hexadecimal Value
INOP
INOP
a
030
FECG
INOP
a
131
US
INOP
a
232
US MECG 5 35
US FECG 9 39
US US2 ; 3B
FECG US < 3C
INOP MECG = 3D
INOP US2 > 3E
a
If HR2 mode is INOP and HR3 mode is MECG, then HR3 mode and data are sent as HR2 mode and data.
Table 11-1. Uterine Activity Modes
UA Mode ASCII Character Hexadecimal Value
INOP 0 30
TOCO 1 31
IUP 2 32
