12-32 120 Series Maternal/Fetal Monitor Revision B
2015590-001
Upgrading a 120 Series Monitor: MECG Option Upgrade Kit
Figure 12-25. MECG Board
Figure 12-26. Main Motherboard
Connect front panel
MECG harness cable here
Switch Pack SW1
Communications
Board Connector
BP Board
Connector
