Revision B 120 Series Maternal/Fetal Monitor 4-33
2015590-001
Theory of Operation: DSP Board
Table 4-16. EL Panel Connector J5 (for 2001904-001 Board)
Pin Number Signal Name Signal Description
1 +12EL +12 Volt Power
2
GNDEL Ground
3
GND Ground
4
No Connection —
5
+5V +5 Volt Supply
6
GNDEL Ground
7
VSYNCB Vertical Sync Line
8
GNDEL Ground
9
HSYNCB Horizontal Sync Line
10
GNDEL Ground
11
VCKB Video Clock
12
GNDEL Ground
13
VDATAB0 Video Data
14
GNDEL Ground
15
VDATAB1 Video Data
16
GNDEL Ground
17
VDATAB2 Video Data
18
GNDEL Ground
19
VDATAB3 Video Data
20
GNDEL Ground
To Next Page
