GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card TSG A015 - Lift Movement Troubleshooting
Page no. 1039 Chapter 9
JC-TSG-A-015.fm
TABLE 2 - LIFT RELATED FRU COMPATIBILITY MATRIX
When following the troubleshooting below consider this compatibility matrix.
FRU compatibility with IB systems [YES/NO]
Lift Type in Install Base System
No brake
(Type 1)
Top brake
(Type 2)
Brake
motor
(Type 3)
Type 2a
(no top brake)
Type 2b
(with top
brake)
FRU P/N Description
5191096
(Obsolete)
Lift Screw Assembly (Type 2) with Motor Obsolete Obsolete Obsolete NO
5212900 Brakeless Lift Motor * YES YES YES NO
5391083 Lift Screw (Type 2) without Motor YES YES YES NO
5373048 Lift Screw (Type 3) without Motor * YES YES NO YES
5413527 Lift Brake Motor (Type 3) NO NO NO YES
5337148 Lift Screw Assembly (Type 3) with Motor YES** YES** YES** YES
5198687 Lift Top Brake Assembly Kit NO YES YES NO
Notes:
* - The Lift Screw (Type 3) without Motor is compatible with both the Brakeless Lift Motor (5212900) and the Lift
Brake Motor (5413527). However, a system already containing the Lift Brake Motor (5413527) must never be
downgraded with a Brakeless Lift Motor (5212900).
** - This FRU can be used as upgrade kit to brake motor design lift
