GE Senographe DS User Manual

Chapter 9 Page no. 1040
JC-TSG-A-015.fm
GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card TSG A015 - Lift Movement Troubleshooting
When using this trouble shooting guide, use illustration 1 to help identify the parts on the Lift.
ILLUSTRATION 1 - GANTRY PARTS
Lift Screw Assembly
Lower Ball Bearing Ring
Lift Motor & Encoder
Can also include an integrated brake
Lift Board
Lift Cardan Nut Assembly
Lift Screw Assembly
Lift Screw Assembly
Ball Bearing Ring
Lift Upper Optical Fork
Lift Gas Spring
Lift Lower Optical Fork
Lift Potentiometer
Rotation Brake
