GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card TSG A015 - Lift Movement Troubleshooting
Page no. 1041 Chapter 9
JC-TSG-A-015.fm
1-3 Preparing the FRUs to take for a troubleshooting onsite visit
Before going onsite to troubleshoot and change parts in the Lift, it is important to know which type of Lift
Screw Assembly is installed in the system, and the nature of the errors. Knowing this information allows
you to determine which parts to take onsite. Table 3 summarizes the parts to take onsite according to the
Lift Screw Assembly type and nature of the errors. The parts listed in table Table 3 are in the order (from
top to bottom) in which they are used in the troubleshooting flowcharts below.
TABLE 3 - FRUS TO TAKE ON SITE DEPENDING ON LIFT TYPE AND NATURE OF ERRORS REPORTED
Type 1
Lift Screw Assembly
Does customer complain about Error 102/024 or does Error 102/024 repeatly
appear in the error logs?
Yes No
• Type 3 Lift Screw Assembly with Brake Motor
(5337148)
• Lift Gas Spring
• Lift Gas Spring
• Type 3 Lift Screw Assembly
with Brake Motor (5337148)
• Lift Board
Type 2
Lift Screw Assembly
Does customer complain about Error 102/024 or does Error 102/024 repeatly
appear in the error logs?
Yes No
Are Errors 102/013 and 102/014 present on a
weekly basis?
• Lift Gas Spring
• Type 2 Lift without Motor
(5391083)
• Brakeless Lift Motor
(5212900)
• Lift Board
Yes No
• Type 3 Lift Screw
Assembly with Brake
Motor (5337148)
• Lift Gas Spring
• Lift Top Brake (5198687)
•Lift Gas Spring
• Type 2 Lift without Motor
(5391083)
• Brakeless Lift Motor
(5212900)
•Lift Board
Type 3
Lift Screw Assembly
Does customer complain about Error 102/024 or does Error 102/024 repeatly
appear in the error logs?
Yes No
• Lift Brake Motor (5413527)
• Lift Gas Spring
• Type 3 Lift without Brake Motor (5373048)
•Lift Board
• Lift Gas Spring
• Type 3 Lift without Brake
Motor (5373048)
• Lift Brake Motor (5413527)
• Lift Board
To Next Page
