GE Senographe DS User Manual

Chapter 3 Page no. 106
S2100D How To.fm
GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Senographe Operations - How to...
ILLUSTRATION 4 -
FOCAL BIAS VOLTAGE
CALIB VOLTAGE
OTHER BIAS VOLTAGE CALIB
Pt: 1st
calcul
2nd
FOCAL BIAS VOLT calcul
VALID
FOCAL BIAS VOLT 1st/ 2nd pt
MeasVCALIB
FOCAL BIAS VOLT measure meas=(value)
NEXT VALID
FOCAL BIAS VOLT display x=(2 values)
CHANGE
FOCAL BIAS VOLT modif x=(2 values)
NEXT
VALID
FOCAL BIAS VOLT Display Focus/Track
CHANGE
FOCAL BIAS VOLTAGE modif x/y (value)
NEXT VALID
THIS MENU IS ONLY
ACCESSIBLE WHEN
BOTH FOCAL BIAS
VOLTAGE VALUES HAVE
BEEN MEASURED AND
ENTERED VIA THE ‘1ST
PT’ OR ‘2ND PT’ MENUS.
THIS MENU IS ONLY ACCESSIBLE
WHEN 1ST OR 2ND PT FOCAL
BIAS VOLTAGE VALUE HAS BEEN
MEASURED VIA THE "CALIB"
MENU.
A
TUBE TYPE
100TH-M1
OTHERS
100TH-M1 BIAS CALIB
PARAM
CALIB
OTHER BIAS CALIB
PARAM
CALIB
IJKLMN PARAM Disp display (6 values)
CHANGE
NEXT
VALID
CALIB 100TH-M1
Pt: 1st
calcul
2nd
3rd 4th
IJKLMN PARAM modif display (6 values)
FOCAL BIAS VOLT 1st/ 2nd/ 3rd/ 4th pt
MeasVCALIB
FOCAL BIAS VOLT measure meas=(value)
NEXT VALID
THIS MENU IS ONLY ACCESSIBLE
WHEN 1ST OR 2ND OR 3RD OR 4TH
PT FOCAL BIAS VOLTAGE VALUE
HAS BEEN MEASURED VIA THE
"CALIB" MENU.
FOCAL BIAS VOLT calcul
VALID
THIS MENU IS ONLY
ACCESSIBLE WHEN BOTH
FOCAL BIAS VOLTAGE
VALUES HAVE BEEN
MEASURED AND ENTERED VIA
THE ‘1ST PT’ OR ‘2ND PT’ OR
‘3RD PT’ OR ‘4TH PT’ MENUS.
FOCAL BIAS VOLT 1st/ 2nd/ 3rd/ 4th pt ref= See
Table 1
FOCAL BIAS VOLT 1st/ 2nd pt ref= See
Table 1
Table 1:
PT 100TH-M1 OTHER
1st Calculated 70 V
2nd Calculated 250 V
3rd Calculated N/A
4th 300 V N/A
