GE Senographe DS User Manual

Chapter 9 Page no. 1060
JC-TSG-A-016.fm
GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card TSG A016 - Rotation Movement Troubleshooting
2 TROUBLESHOOTING STEERING GUIDE
Use the following flow chart to isolate the issue causing the Rotation movement problems.
ILLUSTRATION 1 - TROUBLESHOOTING FLOWCHART
Perform Rotation Functional Checks.
See
section 3-1, Rotation Functional
Checks
on page 1061.
NOK
Grease Checks
See
section 3-4, Grease
Checks
on page 1064.
Grease Rotation Parts
See
section 3-5, Grease Rota-
tion Parts
on page 1066.
NOK
OK
NOK
Rotation Gas Spring Checks
See
section 3-6, Rotation Gas
Spring Checks
on page 1067.
NOK
Change Rotation Gas Spring
See
Job Card D/R A230 - Rota-
tion Gas Spring
on page 1251.
OK
NOK
OK
OK
Check Rotation Motor
See
section 3-7, Rotation Motor
Checks
on page 1068.
NOK
Change Rotation Motor
See
Job Card D/R A228 - Rota-
tion Motor
on page 1243
OK
NOK
Contact OLC.
Change Rotation Board
See
Job Card D/R A221 - Rota-
tion Board
on page 1223.
OK
NOK
OK
Perform Rotation Functional Checks.
See
section 3-1, Rotation Functional
Checks
on page 1061.
Perform Rotation Functional Checks.
See
section 3-1, Rotation Functional
Checks
on page 1061.
Perform Rotation Functional Checks.
See
section 3-1, Rotation Functional
Checks
on page 1061.
Perform Rotation Functional Checks.
See
section 3-1, Rotation Functional
Checks
on page 1061.
Cable Checks
See
section 3-2, Cable Checks
on page 1062.
Re-route cables
See
section 3-3, Cable Re-rout-
ing
on page 1062.
NOK
OK
NOK
OK
Corrective actions
Perform Rotation Functional Checks.
See
section 3-1, Rotation Functional
Checks
on page 1061.
