Chapter 9 Page no. 1076
JC-TSG-A-020.fm
GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card TSG A020 - Generator Power-Up Sequence Flow Charts
2-7 Keep–Alive Voltage Checks on 200PL2
200PL2: Voltage
between "Plus VV"
and 0VV at +12 V?
Yes
No
200PL1: Voltage
between +VE and
0VE at +8 V, and
between –VE and
0VE at –8 V?
Yes
200PL1: Voltage
between TP17 and
0VE at +5 V?
Yes
No
Change 200PL1. End of tests.
No
Wiring between
200PL2 XJ4 and
200PL1 XJ15 OK?
Yes
No
Change 200PL2.
Change wiring
between 200PL2 XJ4
and 200PL1 XJ15.
Wiring between
200PL2 XJ2 and
200PL1 XJ14 OK?
Yes
No
Change 200PL2.
Change wiring
between 200PL2 XJ2
and 200PL1 XJ14.
Keep–alive voltage checks on 200PL2
