GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card D/R A189 - Interface Board
Page no. 1129 Chapter 9
JC-DR-A-189.fm
7 COMPLETION
Once you have changed the Interface board, you must perform the completion steps described below in
the following order:
• section 7-1, Software Check
• section 7-2, Calibrations
7-1 Software Check
Check whether the new Interface Board software needs to be updated, as follows:
1. Reboot the Senographe system.
2. Go to the Service Desktop home page (see Launching the Service Desktop on page 120).
3. Consult Table 1 on page 63 in the section Component FW/SW to ADS Version compatibility Matrix
on page 63. Determine the system level from the ADS/IDC/Generator CPU versions displayed on the
Service Desktop home page, and by consulting Table 1 on page 63. The system level will be defined
by one of the System Level (Model Number) columns in Table 1 on page 63.
4. Check whether the current software version for the new Interface Board corresponds to the required
firmware version for the that system level.
• If the current software version matches the required version quoted in Table 1 on page 63, no
additional steps are required.
• If the current software version does not match the required version, you must perform a sofware
update of the mismatched software version so that the new interface Board software version
matches that quoted in Table 1 on page 63. To update the new Interface Board software follow
the instructions supplied in the Gantry Software Update CD-ROM that is kept with the system.
7-2 Calibrations
Carry out the following calibrations:
Calibrations - Checks Job Card
Check all Gantry motions Job Card ELE A015 - Gantry Functional Checks on page 579
To Next Page
