GE Senographe DS User Manual

Chapter 9 Page no. 1164
JC-DR-A-201.fm
GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card D/R A201 - Lift Board
!
Notice:
When reconnecting all the cables to the Lift Board, ensure that you route them so they do not pass
over Lift Board as illustrated in the diagram above. This precaution avoids potential interference
caused by component electronic noise.
Lift Board cable connections.
Connector
Label
Description of cable
(usually identified by code on a yellow label)
Cable color
J1 J1/PL201-W210 Gray
J2 J2/PL201-W209 Gray
J4 J4/PL201-W201 Gray
J5 J5/PL201-W202 Gray
J6 If the Senographe system has a Type 1 Lift Screw Assembly (no brake), no
cable is attached.
If the Senographe system has a Type 2 Lift Screw Assembly, and has been
fitted with a Top Brake, a black cable with no label, leading up to the Top
Brake located at the top of the Lift Screw Assembly
If the Senographe system has a Type 3 Lift Screw Assembly, a black cable
with no label, going to the Motor Brake located in the Lift Motor at the bot-
tom of the Lift Screw Assembly
Black (if
brake exists)
J9 J9/PL201 or PL202 - W205 Black
J10 J10/PL201 or PL202 - W206 Black/Grey
J11 J11/PL201-W203 Gray
J12 J12/PL201-W211 Gray
J13 J13/PL201-W208 Gray
J14 J14/PL201-W213 Gray
J15 Gray ribbon cable to the Gantry digital display Gray
J16 Footwsitch cable with 9 pin D-sub connector N/A
J17 Footwsitch cable with 9 pin D-sub connector N/A
J21 No cable attached N/A
J22 No cable attached N/A
J23 No cable attached N/A
