Chapter 9 Page no. 1198
JC-DR-A-210.fm
GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card D/R A210 - Gantry cover replacement guide
• Identify each of these parts in the following summary table.
The table gives the locations of part replacement information in this Job Card.
• If you cannot find a reference number on the cover, use the number given in section 4 page 1213.
TABLE 1 - COVER REPLACEMENT SUMMARY
Reference no. Description For replacement, see:
2375024 Detector Cover Upper section 3-7-1 page 1209
2375024-2 section 3-7-2 page 1209
2375024-3 section 3-7-1 page 1209
2375025 Detector Cover Lower section 3-7-1 page 1209
2375025-2 section 3-7-2 page 1209
2375025-3 section 3-7-1 page 1209
2375027 Column Cover Top Left section 3-3-1 page 1201
2375027-2 section 3-3-2 page 1201
2375027-3 section 3-3-1 page 1201
2375028 Column Cover Top Right section 3-3-1 page 1201
2375028-2 section 3-3-2 page 1201
2375028-3 section 3-3-1 page 1201
2375029 Column Cable Exit section 3-3-1 page 1201
2375029-2 section 3-3-2 page 1201
2375029-3 section 3-3-1 page 1201
2375030 Column Cover Bottom Front section 3-3-1 page 1201
2375030-2 section 3-3-2 page 1201
2375030-3 section 3-3-1 page 1201
2375031 Column Cover Bottom Rear section 3-3-1 page 1201
2375031-2 section 3-3-2 page 1201
2375031-3 section 3-3-1 page 1201
2375032 Column Cover Front Left section 3-3-1 page 1201
2375032-2 section 3-3-2 page 1201
2375032-3 section 3-3-1 page 1201
2375033 Column Cover Front Right section 3-3-1 page 1201
2375033-2 section 3-3-2 page 1201
2375033-3 section 3-3-1 page 1201
2375037 Arm Cover Left section 3-4-1 page 1203
2375037-2 section 3-4-2 page 1203
2375037-3 section 3-4-1 page 1203
2375037-4 section 3-4-2 page 1203
2375038 Arm Cover Right section 3-4-1 page 1203
2375038-2 section 3-4-2 page 1203
2375038-3 section 3-4-1 page 1203
2375038-4 section 3-4-2 page 1203
