Job Card D/R A210 - Gantry cover replacement guide
Page no. 1209 Chapter 9
JC-DR-A-210.fm
3-7-1 Detector Covers - non-available covers
• If the reference of the defective part appears in the following table, it cannot be replaced individually.
A complete set of covers must be ordered and installed:
- Order a set of covers as listed below:
• The Detector must be modified to accept the new covers. Refer to section 3-9 page 1211.
• The new Detector/Positioner Interface Plate reference 2408213, together with the new Quick Fix
Assembly, reference 2411952, must be installed in place of the existing Interface Plate. Refer to sec-
tion 3-10 page 1212.
• After modifying the detector and changing the interface plate, install the new covers using the infor-
mation given in Job Card PHY A044 - Remove/Reinstall Gantry Covers, section 10 page 530.
3-7-2 Detector Covers - available covers
If the reference of the defective part appears in the following table, it can be replaced individually.
The table indicates the necessary part(s) to be ordered
• Install the new cover(s) using the information given in Job Card PHY A044 - Remove/Reinstall Gan-
try Covers, section 10 page 530.
Reference Description
2375024 2375024-3 Detector Cover Upper
2375025 2375025-3 Detector Cover Lower
Reference Description Quantity
2375024-2 Detector Cover Upper 1
2375025-2 Detector Cover Lower 1
2411952 Quick Fix Assy for Detector Covers 1
2408213 Interface Plate Equipped 1
If the defective part is:
Order the following parts:
Reference Description Quantity
2375024-2 Detector Cover Upper 2375024-2 Detector Cover Upper 1
2375025-2 Detector Cover Lower 2375025-2 Detector Cover Lower 1
