GE Senographe DS User Manual

GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card D/R A250 - Compression Board
Page no. 1329 Chapter 9
JC-DR-A-250.fm
7 COMPLETION
7-1 Firmware Check
Check whether the new Compression Board firmware needs to be updated, as follows:
1. Reboot the Senographe system.
2. Go to the Service Desktop home page (see Launching the Service Desktop on page 120).
3. Consult Table 1 on page 63 in the section Component FW/SW to ADS Version compatibility Matrix
on page 63. Determine the system level from the ADS/IDC/Generator CPU versions displayed on the
Service Desktop home page, and by consulting Table 1 on page 63. The system level will be defined
by one of the System Level (Model Number) columns in Table 1 on page 63.
4. Check whether the current firmware version(s) for the new Compression Board corresponds to the
required firmware version for the that system level.
• If the current firmware version(s) match the required version(s) quoted in Table 1 on page 63, no
additional steps are required.
• If the current firmware version(s) does not match the required version(s), you must perform a firm-
ware update of the mismatched firmware version(s) so that the new Compression Board firmware
version(s) match those quoted in Table 1 on page 63. To update the new Compression Board
firmware follow the instructions supplied in the Gantry Software Update CD-ROM that is kept with
the system.
7-2 Calibrations
• Check compression motion and keypad.
• Carry out the following calibration (and verification) procedures:
Calibrations - Checks Job Card
Gantry
Compression Force Sensor Cali-
bration
Compression Force Calibration on page 1709 in Job Card CAL A048
- Calibration of Compression Force Sensor
Compression Thickness Calibration
Compression Thickness Calibration on page 1721 in Job Card CAL
A050 - Compression Thickness Calibration
Compression Force Calibration
Verification
Verification of the Compression Force Sensor calibration on page
1710
in Job Card CAL A048 - Calibration of Compression Force
Sensor
Compression Thickness Calibra-
tion Verification
Check the Thickness Measurement in Contact Mode on page 1722
in Job Card CAL A050 - Compression Thickness Calibration
If Compression Thickness not OK, repeat calibrations from Compression Force Sensor
AOP/SNR Check Job Card ELE A038 - AOP Mode and SNR Check on page 707
If AOP/SNR Test not OK, repeat all calibrations
