Chapter 9 Page no. 1470
JC-DR-A-318.fm
GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card D/R A318 - LCD Monitor
Note:
For Penduick and above, a system with a 19” LCD Monitor can be upgraded to the 21" 3MP LCD
Monitor if the customer has paid for that option.
2 APPLICABILITY
Three types of Rotative Arm Sets exist, as follows:
• Ergotron A (introduced with V1 Control Stations) - contains one rotative arm support and two exten-
sion (rotative) arms
• Ergotron B (introduced with V2 Control Stations) - contains one rotative arm support and two exten-
sion (rotative) arms
• Sisfle (introduced with V3/V4 Control Stations) - contains one rotative arm support and one extension
(rotative) arm
The procedure used in this Job Card vary according to the type of rotative arm you have.
This Job Card is only applicable to the V2/V3/V4 Control Station.
3TOOLS
Standard Tool Box
4 REQUIRED EFFORT
Personnel: 1 Field Engineer
Time: 15 minutes
5 SAFETY PRECAUTIONS
WARNING
Before beginning work, shut down the equipment and switch off the Generator hospital
supply circuit breaker. Lock it in the off position or mark it clearly with a warning sign to
prevent others from applying power.
Never switch off at the UPS except in emergency (risk of data loss).
6 PREREQUISITES
None
7 PROCEDURE
• If you are changing an 18" or 19" LCD Monitor for another 18" or 19" LCD Monitor, refer to section 7-
1, 18" and 19" Monitors.
• If you are changing an 21" 3MP LCD Monitor for another 21" 3MP LCD Monitor, refer to section 7-2,
21" 3MP Monitor.
53.40 or above
(Penduick or above)
18" LCD Monitor (2403952-4) 19" LCD Monitor with BNC connectors
(5397967)
19" LCD Monitor (5148720-4) 19" LCD Monitor (5148720-4)
21" 3MP LCD Monitor (5370904) 21" 3MP LCD Monitor (5370904)
ADS Version Existing Monitor New Monitor
To Next Page
