Scenario PM A001 - Planned Maintenance Steering Guide
Gantry:
Remove Gantry covers. Job Card PHY A044 - Remove/Reinstall Gantry
Covers: p. 523
12 20 X X X
Check Breast Thickness Measurement Job Card ELE A015 - Gantry Functional Checks -
section 6-9 Check Breast Thickness Measure-
ment: p. 581
6 10XXXXXX
Check Gantry functions Job Card PM A201 - Gantry operational checks:
p. 1777
12 10 X X X
Check for correct collimation Job Card ELE A028 - Collimation Checks: p. 679 12 20 X X X
Check and lubricate Gantry mechanisms Job Card PM A205 - Mechanical checks and lubri-
cation: p. 1779
12 20 X X X
Reinstall Gantry covers Job Card PHY A044 - Remove/Reinstall Gantry
Covers: p. 523
12 30 X X X
Check Manual Compression maximum
force.
Job Card ELE A017 - Manual Compression
Check and Calibration: p. 583
12 10 X X X
Check Gantry emergency stop buttons. Check operation of both Gantry emergency stop
buttons. Check that all movement of the Ganttry is
stopped when either button is pressed.
12 5 X X X
Control Station
Check UPS function Job Card CHK A003 - UPS Batteries section 6
UPS Function Check: p. 1737
6 5 XXXXXX
Recalibrate UPS Battery Capacity Job Card CHK A003 - UPS Batteries section 7
Battery Capacity Re-Calibration: p. 1738
12 10 X X X
Remove Control Station covers Job Card PHY A040 - Remove/Reinstall Control
Station Covers on page 503
6 10XXXXXX
Change AWS (U20) Motherboard battery
(V3 Control Stations only)
Job Card D/R A335 - AWS (U20) Motherboard
Battery (V3 Control Stations only) on page 1537
12 15 X X X
Clean IDC air filter (only applicable on sys-
tems with the Dione 5 IDC)
Job Card PM A425 - IDC Air Filter Cleaning on
page 1803
6 10XXXXXX
Reinstall Control Station covers Job Card PHY A040 - Remove/Reinstall Control
Station Covers on page 503
6 10XXXXXX
Task Title Task Definition Int.
mth.
Drn.
min.
PM Visit no.
123456
