2-7-3. Supply Command Board 200PL2 Neon Lights
2-7-4. Supply Command Board 200PL2 Fuses
DE3 Heater Meter at Maximum Limit Red Normal status: OFF
ON when the heater meter has reached the maxi-
mum value. This is normal after some important
stop/starts. In this case cut the power to the Gener-
ator and power it back up. If the DE3 LED system-
atically is on after restarting the Generator, replace
the Supply Command Board 200PL2.
OFF when the heater meter is operating normally
and has not reached its maximum limit.
LED Function Color Behavior
N1 250 V from the Transformer present Orange Normal status: ON
ON when the 250 V supply from the Generator
Transformer is present.
OFF when 250 V supply from the Generator Trans-
former is not present. In this case, proceed as fol-
lows:
• Check the F6 fuse, and change if necessary.
• Check the status of the N1 and N2 neon lights on
the Mains Distribution Board 200PL1.
If N1 and N2 are ON there is a problem with either
the Generator Transformer or the cabling of the
Generator Transformer. Check the cabling within
the Generator Transformer and on the K1 contact
and XJ10 connector.
If N1 is OFF and N2 is ON there is possibly a
problem with the X1 relay on the Mains Distribu-
tion Board 200PL1, and you must change the
Mains Distribution Board 200PL1.
Fuse Specification PN Function
F1 250 Vac, 3.15 A, Delay 99194288 3.15 A / 250 V (+27 V X-ray Console)
F2 250 Vac, 0.5 A, Delay 58079685 0.5 A / 250 V +27 V fan)
F3 150 Vac, 125 A, Fast 91684676 125 A/150 V (27 V AC)
F4 380 Vac, 10 A, Fast 58079166 10 A/380 V (starter, 250 V)
F5 10 A/380 V (heater, BT supply, 250 V)
F6 250 Vac, 16 A, Fast 58079690 16 A/250 V (250 V AC)
