GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Central Listing
Page no. 273 Chapter 3
Indicators and Switches.fm
2-7-5. Supply Command Board 200PL2 Test Points
Test Point Label (in French) Function (in English)
PT1 Inib Decomptage Inhibit counting B11
PT2 Contact K2 K2 Contact
PT3 Alim Puissance OK Power Supply OK
PT4 Pres. Alim Supply Present
PT5 250 V < E < 700 V 250 V < E < 700 V
PT6 Cde Contacteur K1 Power Switch Command
PT7 MST Power ON
PT8 Teta_Sup_Tmax Overtemperature
PT9 RAZ 3 s Reset Counter B11
PT10 Demande MST Power ON Request
PT11 T_Sup_3S Delay > 3 s
PT12 7.63 Hz 7.63 Hz Clock
PT13 Echauffement Clock Counter B8
PT14 Auto MST Automatic Power ON Signal
PT15 B13 Output B13 Counter Outpuy
PT16 15.6 kHz Clock 15.6 kHz Clock
PT17 Contacteur K1 Switch Command
PT18 +VLC (+12 V) +12 V
PT19 Cde Precharge Precharge DC Bus Command
PT20 Threshold pres acceleration + 174 mV DC Voltage
PT21 Threshold lanceur actif +20 mV DC Voltage
P250V +250 V +250 V present
P27V +27 V +27 V present
0V/250V 0 V (250 V) Ground for 250 V supply
0V/27V 0 V (27 V) Ground for 27 V supply
