Chapter 3 Page no. 274
Indicators and Switches.fm
GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Central Listing
2-8. Relay Board 200PL4
2-8-1. Relay Board 200PL4 Connectors
Connector Function
XJ1 X-ray Room Lamp Indicator Cable - Senographe System ON
XJ2 X-ray Room Lamp Indicator Cable - X-ray ON
XJ3 X-ray Room Lamp Indicator Cable - Room Door
XJ4 To the XJ4 connector on the Supply Command Board 200PL2 (control signals)
XJ1
XJ2
XJ3
XJ4
