GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Cable Lay-out and Pin-out
Page no. 307 Chapter 3
Cables.FM
1-39. W213 - POS-Bus 1 between Boards
Rotation Board PL202 J3 to Lift Board PL201 J14.
1-40. W215 - Rotation Optical Fork Connect
Rotation Board PL202 J5 to optical detector S203.
1-41. W216 - Stop Motion Connect (Right)
Emergency Stop R-Button S205 to Interface Board PL104 J6.
1-42. W217 - Stop Motion Connect (Left)
Emergency Stop L-Button S206 to Interface Board PL104 J7.
1-43. W218/221 - Clutch Cables
W218: Clutch B201 to Rotation Board PL202 J8.
W221: Clutch B201 to Rotation Board PL202 J7.
PIN (PL202) Designation Type Level PIN (PL201)
PL202/J3-1 H-CAN Network CAN Diff 5 / 2.5V PL201/J14-1
PL202/J3-2 L-CAN Network CAN Diff 2.5 / 0V PL201/J14-2
PL202/J3-3 GND Ground 0 V PL201/J14-3
PL202/J3-4 H-RT line 1 RT-CAN Diff 5 / 2.5 V PL201/J14-4
PL202/J3-5 L-RT line 1 RT-CAN Diff 2.5 / 0V PL201/J14-5
PL202/J3-6 Stop motion RT 0/+5 V PL201/J14-6
PL202/J3-7 H-RT line 2 RT-CAN Diff 5 / 2.5 V PL201/J14-7
PL202/J3-8 L-RT line 2 RT-CAN Diff 2.5 / 0V PL201/J14-8
PL202/J3-9 Reset line RT 0/+5 V PL201/J14-9
PL202/J3-10 GND Ground 0 V PL201/J14-10
PL202/J3-11 H-RT line 3 RT-CAN Diff 5 / 2.5 V PL201/J14-11
PL202/J3-12 L-RT line 3 RT-CAN Diff 2.5 / 0V PL201/J14-12
Designation Type Level Pin N°
VCC_Led_1 VCC 5 V J5-1
GND Ground 0 V J5-2
Fork_Opt_Out_1 Open coll. 0 / +5 V J5-3
GND Ground 0 V J5-4
