Chapter 3 Page no. 306
Cables.FM
GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Cable Lay-out and Pin-out
1-35. W209 - 48 V LP1
See W114/W116/W209 - PDU Board J7 Connections on page 302.
1-36. W210 - 48 V DC HP
Lift Board PL201 J1 to MPCB Terminal 1 ST102.
1-37. W211 - 48 V DC HP between Boards
Lift Board PL201 J12 to Rotation Board PL202 J1.
1-38. W212 - 48 V DC LP1
Lift Board PL201 J13 to Rotation Board PL202 J2.
N° Pin Functions
J1-1 + 48 Volts
J1-2 0 Volt
N° Pin Functions
J12-1 0 Volt
J12-2 + 48 Volts (max. 15 A avg. 30 A (3 s))
N° Pin Functions
J13-1 0 Volt
J13-2 + 48 Volts (max. 100 mA)
