Chapter 3 Page no. 308
Cables.FM
GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Cable Lay-out and Pin-out
1-44. W219 - Electromagnetic Brake Connect
Electromagnetic Brake B202 to rotation Board PL202 J6.
1-45. W220 - Rotation Potentiometer
Potentiometer R202 to Rotation Board PL202 J11.
1-46. W221 - Clutch Cable
See W218.
1-47. W222 - Footswitch Cable
See W207.
1-48. W301 - Compression Stepper Motor
Stepper Motor M301 to Compression Board PL303 J3.
Designation Type Level Pin N°
VCC VCC 5 V J11-1
Pot. analog 0 / +5 V J11-2
GND Ground 0 V J11-3
Color ITEM
Red +DC 5 V
Orange GND
Yellow NC
Brown NC
Blue A-Channel
Green /A-Channel
Gray B-Channel
Violet /B-Channel
Tbd C-Channel
White /C-Channel
Designation Type Level Pin N°
OUT_1A Hbridge 0 / 48 Volts J3-1
OUT_1B Hbridge 0 / 48 Volts J3-2
OUT_2A Hbridge 0 / 48 Volts J3-3
OUT_2B Hbridge 0 / 48 Volts J3-4
