GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Cable Lay-out and Pin-out
Page no. 309 Chapter 3
Cables.FM
1-49. W302 - Compression Stepper Encoder
Encoder U301 to Compression Board PL303 J4:
1-50. W303 - Compression Potentiometer Connect
Potentiometer R301 to Compression Board PL303 J6:
1-51. W304A/W304B - Paddle Detector Card Connect
Paddle detector PL304 J2 to Compression Board PL303 J10:
Designation Type Level Pin N°
+DC 5 V VCC 5 V J4-1
GND 0V Ground J4-2
A-Channel TTL 0/+5 V J4-5
/A-Channel TTL 0/+5 V J4-6
B-Channel TTL 0/+5 V J4-7
/B-Channel TTL 0/+5 V J4-8
C-Channel TTL 0/+5 V J4-9
/C-Channel TTL 0/+5 V J4-10
Designation Type Level Pin N°
VCC VCC 5 V J6-1
Pot. Analog. 0/5 V J6-2
GND Ground 0 V J6-3
Designation Level Pin N°.
VCC 5 V J10-1
GND 0 V J10-2
Force_Sensor Analog J10-3
Paddles bit 0 (LSB) Open collector J10-4
Paddles bit 1 Open collector J10-5
Paddles bit 2 Open collector J10-6
Paddles bit 3 Open collector J10-7
Paddles bit 4 (MSB) Open collector J10-8
Pos_Paddles bit 0 (LSB) Open collector J10-9
Pos_Paddles bit 1 (MsSB) Open collector J10-10
Brake_1 + 48 V J10-11
Brake_2 Open collector J10-12
