Chapter 3 Page no. 310
Cables.FM
GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Cable Lay-out and Pin-out
1-52. W305 - Arm Control Keypad Connect
FromArm Control Keypad PL305 J1 (on right or left of Arm) to Compression Board PL303 J7 or J8:
1-53. W306 - Earth Cable Arm Connect
Arm to ground bar G301.
1-54. W307 - 48v dc-LP2 for Compression
Arm Distribution Board PL301 J5 to Compression Board PL303 J1:
Designation Level Pin N°
Lift up slow speed_A Contact to gnd J7/J8-1
Lift up slow speed_B Contact to gnd J7/J8-2
Lift up High speed_A Contact to gnd J7/J8-3
Lift up High speed_B Contact to gnd J7/J8-4
Lift down slow speed_A Contact to gnd J7/J8-5
Lift down slow speed_B Contact to gnd J7/J8-7
Lift down High speed_A Contact to gnd J7/J8-6
Lift down High speed_B Contact to gnd J7/J8-8
Rotation left slow speed_A Contact to gnd J7/J8-9
Rotation left slow speed_B Contact to gnd J7/J8-10
Rotation left high speed_A Contact to gnd J7/J8-11
Rotation left high speed_B Contact to gnd J7/J8-12
Rotation right slow speed_A Contact to gnd J7/J8-13
Rotation right slow speed_B Contact to gnd J7/J8-14
Rotation right high speed_A Contact to gnd J7/J8-15
Rotation right high speed_B Contact to gnd J7/J8-16
MLO_R_A Contact to gnd J7/J8-17
MLO_R_B Contact to gnd J7/J8-18
MLO_L_A Contact to gnd J7/J8-19
MLO_L_B Contact to gnd J7/J8-20
CC_A Contact to gnd J7/J8-21
CC_B Contact to gnd J7/J8-22
Spare_1_A Contact to gnd J7/J8-23
Spare_2_B Contact to gnd J7/J8-24
GND GND J7/J8-25
+VCC 5 V VCC J7/J8-26
Pin N° Function Pin N°
PL301/J5-1 48 Volts PL303/J1-1
PL301/J5-2 GND PL303/J1-2
