Page #311 background imageLoading...
Page #311 background image
GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Cable Lay-out and Pin-out
Page no. 311 Chapter 3
Cables.FM
1-55. W308 - POS-Bus 2 Compression Connect
Compression Board PL303 J2 to Arm Distribution Board PL301 J6:
1-56. W309 - Screw Brake Connect
Screw brake B303 to Compression Board PL303 J5:
1-57. W310 - 48V to Bucky Board
P/N: 2372183
Distribution Board PL301 J4 to connector J4a, then from J2a to Bucky Board PL302 J2:
1-58. W311 - POS-Bus 2 for Bucky
Distribution Board PL301 J3 to connector J3a, then from J1a to Bucky Board PL302 J1:
Pin N° Designation Level Pin N°
J2-1 CAN Diff 5 / 2.5 V J6-1
J2-2 CAN Diff 2.5 / 0 V J6-2
J2-3 Ground 0 V J6-3
J2-4 RT-CAN Diff 5 / 2.5 V J6-4
J2-5 RT-CAN Diff 2.5 / 0 V J6-5
J2-6 RT 0 V J6-6
J2-7 RT-CAN Diff 5 / 2.5 V J6-7
J2-8 RT-CAN Diff 2.5 / 0 V J6-8
J2-9 RT 0 / +5 V J6-9
J2-10 Ground 0 V J6-10
J2-11 RT-CAN Diff 5 / 2.5 V J6-11
J2-12 RT-CAN Diff 2.5 / 0 V J6-12
Color Designation Type Level Pin N°
Green/Red VCC_48 VCC 48 Volts J5-1
Green/Blue Cmd_Brake Open Coll. 0 / 48 Volts J5-2
N° Pin Functions N° Pin
J4/J4a-1 + 48 Volts J2/J2a-1
J4/J4a-2 GND J2/J2a-2
PIN (PL301) Designation Type Level PIN (PL302)
PL301/J3-1 H-CAN Network CAN Diff 5 / 2.5V PL302/J1-1
PL301/J3-2 L-CAN Network CAN Diff 2.5 / 0V PL302/J1-2
PL301/J3-3 GND Ground 0 V PL302/J1-3
PL301/J3-4 Not Used
PL301/J3-5 Not Used
PL301/J3-6 Not Used
