GE Senographe DS User Manual

GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Cable Lay-out and Pin-out
Page no. 313 Chapter 3
Cables.FM
1-61. W314 - SYS-POS-Bus Cable
Interface Board PL104 J5 to Arm Distribution Board PL301 J1:
PIN (PL104) Designation Type Level
J5-1 H-CAN Bus Column CAN Diff 5 / 2.5V
J5-2 GND Ground 0 V
J5-3 L-CAN RT1 Column RT-CAN Diff 2.5 / 0V
J5-4 L-CAN RT2 Column RT-CAN Diff 5 / 2.5V
J5-5 Reset Line Column RT 0/+5 V
J5-6 H-CAN RT3 Column RT-CAN Diff 5 / 2.5V
J5-7 H-Expose Enable RT 0/+5 V
J5-8 Spare N/A N/A
J5-9 H-Expose Command RT 0/+5 V
J5-10 GND Ground 0 V
J5-11 H-Xray On RT 0/+5 V
J5-12 P-Power On RT 0/+5 V
J5-13 H-Motion Enable RT 0/+5 V
J5-14 Command CAN Electric CAN 0 V (CAN Gnd)
J5-15 H-CAN Network CAN Diff 5 / 2.5V
J5-16 H-Spare N/A N/A
J5-17 NC N/A N/A
J5-18 NC N/A N/A
J5-19 NC N/A N/A
J5-20 L-CAN Bus Column CAN Diff 2.5 / 0 V
J5-21 Stop Motion Line Column RT 0/+5 V
J5-22 H-CAN RT1 Column RT-CAN Diff 5 / 2.5 V
J5-23 L-CAN RT2 Column RT-CAN Diff 2.5 / 0 V
J5-24 GND Ground 0V
J5-25 L-CAN RT3 Column RT-CAN Diff 2.5 / 0 V
J5-26 L-Expose Enable RT-CAN 0/+2.5 V
J5-27 GND Ground 0 V
J5-28 L-Expose Command RT-CAN 0/+2.5 V
J5-29 P-Reset RT 0 V
J5-30 L-Xray On Ground 0/+2.5 V
J5-31 L-Power On RT 0/+2.5 V
J5-32 L-Motion Enable RT 0/+2.5 V
J5-33 P-Power Supply 2.4W PWR 12 V (200 mA)
J5-34 L-CAN Network CAN Diff 2.5 / 0 V
J5-35 L-Spare N/A N/A
J5-36 NC N/A N/A
J5-37 NC N/A N/A
