Chapter 3 Page no. 314
Cables.FM
GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Cable Lay-out and Pin-out
1-62. W315 - 48v dc-LP2
PDU Board PL101 J6 to Arm Distribution Board PL301 J2:
1-63. W316 - Image Receptor Earth Connect
Ground bar G301 to Image receptor.
1-64. W317 - Compression Trolley Earth Connect
Ground bar G301 to Compression Trolley.
1-65. W318 - Compression Block Connect
Manual Brake B301 to Paddle Detect. Board PL304:
Green/Blue (-) Green/Red (+)
1-66. W319 - Force Sensor
Force Sensor B302 to Paddle Detect. Board PL304.
1-67. W320 - Earth Cable for Paddle Holder
Paddle Holder PL304 to Ground.
1-68. W401 - 48v dc-LP2
Arm Distribution Board PL301 J8 to Collimator DC/DC PL402 J5:
1-69. W402 - Thermoswitch Connect
N° Pin Functions N° Pin
J6-1 + 48 Volts J2-1
J6-2 GND J2-2
PIN Function PIN
J1-1 0 Volts J8-2
J1-2 + 48 Volts J8-1
Designation Level Pin N°
Power supply 15 V J4-2
secu_sheath 15 V or 0 V(failure) J4-1
To Next Page
