Chapter 3 Page no. 316
Cables.FM
GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Cable Lay-out and Pin-out
1-74. W407 - Arm Control Keypad Connect
From Arm Control Keypad PL404 J1 (on right or left of Tube Head) to Tilt Board PL401 J7 or J8:
1-75. W408 - Earth Cable X-ray Tube
Ground bar G301 to the X-ray Tube.
Designation Level Pin N°
Lift up slow speed_A Contact to gnd J7/J8-1
Lift up slow speed_B Contact to gnd J7/J8-2
Lift up High speed_A Contact to gnd J7/J8-3
Lift up High speed_B Contact to gnd J7/J8-4
Lift down slow speed_A Contact to gnd J7/J8-5
Lift down slow speed_B Contact to gnd J7/J8-7
Lift down High speed_A Contact to gnd J7/J8-6
Lift down High speed_B Contact to gnd J7/J8-8
Rotation left slow speed_A Contact to gnd J7/J8-9
Rotation left slow speed_B Contact to gnd J7/J8-10
Rotation left high speed_A Contact to gnd J7/J8-11
Rotation left high speed_B Contact to gnd J7/J8-12
Rotation right slow speed_A Contact to gnd J7/J8-13
Rotation right slow speed_B Contact to gnd J7/J8-14
Rotation right high speed_A Contact to gnd J7/J8-15
Rotation right high speed_B Contact to gnd J7/J8-16
MLO_R_A Contact to gnd J7/J8-17
MLO_R_B Contact to gnd J7/J8-18
MLO_L_A Contact to gnd J7/J8-19
MLO_L_B Contact to gnd J7/J8-20
CC_A Contact to gnd J7/J8-21
CC_B Contact to gnd J7/J8-22
Spare_1_A Contact to gnd J7/J8-23
Spare_2_B Contact to gnd J7/J8-24
GND GND J7/J8-25
+VCC 5 V VCC J7/J8-26
