GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Cable Lay-out and Pin-out
Page no. 317 Chapter 3
Cables.FM
1-76. W409 - SYS-Bus-2 Collimator Connect
Arm Distribution Board PL301 J7 to Collimator PL403 J1:
1-77. W410 - 48 V DC-LP2 Tilting Connect
Arm Distribution Board PL301 J10 to Tilt Board PL401 J1:
Signal name Signal nature Pin N°
H-Expose Enable RT-CAN Diff 5/2.5V J7-1
L-Expose Enable RT-CAN Diff 2.5/0V J7-2
Spare J7-3
0 Power supply Ground J7-4
H-Expose Command RT-CAN Diff 5/2.5V J7-5
L-Expose Command RT-CAN Diff 2.5/0V J7-6
Ground Ground J7-7
P Reset Command RT 0/+5V J7-8
H-Xray On RT-CAN Diff 5/2.5V J7-9
L-Xray On RT-CAN Diff 2.5/0V J7-10
P Power On Command/reserved J7-11
L Power On Command/reserved J7-12
H-Motion Enable RT-CAN Diff 5/2.5V J7-13
L-Motion Enable RT-CAN Diff 2.5/0V J7-14
Common CAN Electric CAN Ground J7-15
P Power supply 12 V J7-16
H-CAN Network CAN Diff 5/2.5V J7-17
L-CAN Network CAN Diff 2.5/0V J7-18
H-Spare RT-CAN Diff 5/2.5V J7-19
L-Spare RT-CAN Diff 2.5/0V J7-20
PIN N° Function Pin N°
J10-1 + 48 Volts J1-1
J10-2 GND J1-2
