Job Card PHY A030 - Generator and Gantry Disconnection Reconnection
Location within Generator Connection Cable description or label C D R
Conditioner Unit In Red coolant pipe (no label)
Out Red coolant pipe (no label)
RS-232 Gray cable with the 9-pin D-type connector,
labeled Cond. Cab. Cond. 2226611 *
MDR XP4 Black power cable with the IEC type 320 female
end, labeled XJ4 Cond. Cab. 2225470
XP5 Black power cable with the IEC type 320 female
end, labeled XP5 Cond. Cab. 2386021
Generator Interface Board
400PL2
XJ4 Gray cable with the 9-pin D-type connector,
labeled XJ4 GENE 400 PL2 2226623 *
XJ10 Blue cable with the 25-pin D-type connector,
labeled XJ10 GENE 400 PL2 2226613
XJ6 Black optical fiber labeled
400 PL2 XJ6 2381702
XJ7 Black optical fiber labeled
400 PL2 XJ7 2381704
XJ9 Black optical fiber labeled
400 PL2 XJ9 2381706
Mains Distribution Board
200PL1
XJ1 Blue cable with labeled PH2, originating from a
thick white cable labeled 2381711
XJ3 Pink cable with labeled PH1, originating from a
thick white cable labeled 2381711
Power Line Filter Box Earth Green/yellow earth cable, originating from a thick
white cable labeled 2381711
Supply Command Board
200PL2
Bolt above
XJ1
Black cable with blue plastic end,
originating from white cable labeled
Gene W125 - 2381710
TP10 Black cable with red plastic end,
originating from white cable labeled
Gene W125 - 2381710
Anode Starter Board 300PL2 XJ2 Gray cable labeled G300-PL2 XP1 2381701 with
exposed shielding ending with three black cables
to a black connector.
Auto Transformer Orange block
to BR1
Black cable, originating from white cable labeled
Gene W125 - 2381710
Orange block
to TH1
Black cable, originating from white cable labeled
Gene W125 - 2381710
HV Tank Earth symbol Thin black cable with red plastic end, labeled HT+
GND / 2381701
N/A HV Cable N/
A
N/
A
Notes:
* - Because there are two cables with the same 9-pin D-type connector originating from the same conduit,
you must pay special attention to ensure that you re-connect them to the correct place.
From Conduit 1 (see section 6-2)From Conduit 2 (see section 6-3)
