GE Senographe DS User Manual

Chapter 7 Page no. 550
JC-ELE-A-008.fm
GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card ELE A008 - Configuring the 21-inch 3MP Monitor
4 SAFETY PRECAUTIONS
None
5 APPLICABILITY
This Job Card is only applicable to Senographe systems running ADS 53.40 and above, which have
optional the 21-inch 3 MP Monitor installed. The 21-inch 3 MP Monitor is only available for V3 and V4
Control Stations.
6 PREREQUISITES
The 21-inch 3 MP Monitor has been physically connected during the physical installation phase of the
Senographe system.
Note:
Ensure that the monitor DVI cable is connected to the left hand side DVI connector on the back of
the ADS computer.
7 PROCEDURE
7-1 Resolution Configuration
The steps you undertake depend on whether you have a V3 or V4 Control Station, as summarized in the
following steering guide.
7-1-1 Resolution Configuration on V3 Control Stations
1. Reboot the ADS Workstation to ensure that you are at the first Login: prompt.
A series of system initialization messages appears on the screen, then the Login: prompt appears.
2. Login as the root user as follows:
a. At the Login: prompt, enter:
root
b. At the Password: prompt, enter:
operator
A command prompt appears for the root user.
3. At command prompt, launch the Desktop Manager Configuration Tool, by entering:
kdmconfig
Perform kdmconfig to set monitor size
and resolution - see section 7-1-1, Res-
olution Configuration on V3 Control Sta-
tions on page 550.
Expand ADS GUI to Fill the Entire Monitor
See section 7-1-3, Expanding the ADS GUI to Fill the Monitor (V3 and V4 Control Stations) on page 552.
Nothing to do as Z400 uses Xorg server
for the graphics management which
auto-detects - see section 7-1-2, Reso-
lution Configuration on V4 Control Sta-
tions on page 551.
V3 Control Stations
(U20 - Xsun server)
V4 Control Stations
(Z400 - Xorg server)
