GE Senographe DS

GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
ERR SUB A001 - Generator Error Messages
Page no. 837 Chapter 9
ERR-SUB-A-001.fm
022/006 E10 Heating failure
track 1
Heater track 1: mA value not significant
022/007 E10 Heating failure
track 1
Heater track 1: signal Pres_Chauf
(Heater_Presence) goes ’low’ after
exposure
022/008 E10 Heating failure
track 1
Heater track 1: signal Pres_Chauf
(Heater_Presence) stays ’high’ when
the heater stopped
023/001 E11 Heating failure
track 2
Heater track 2: signal Pres_Chauf
(Heater_Presence) ’high’ in standby
status
023/002 E11 Heating failure
track 2
Heater track 2: signal Pres_Chauf
(Heater_Presence) stays ’low’ when the
heater started
023/003 E11 Heating failure
track 2
Heater track 2: signal Pres_Chauf
(Heater_Presence) goes ’low’ during
pre-heater phase
023/004 E11 Heating failure
track 2
Heater track 2: signal Pres_Chauf
(Heater_Presence) goes ’low’ during
first trigger
023/005 E11 Heating failure
track 2
Heater track 2: signal Pres_Chauf
(Heater_Presence) goes ’low’ during
exposure
023/006 E11 Heating failure
track 2
Heater track 2: mA value not significant
023/007 E11 Heating failure
track 2
Heater track 2: signal Pres_Chauf
(Heater_Presence) ’low’ after exposure
023/008 E11 Heating failure
track 2
Heater track 2: signal Pres_Chauf
(Heater_Presence) stays ’high’ when
the heater stopped
027/003 E04 Arm fatal failure If the problem occurs during boot,
check optical fiber between Gantry
interface board and generator, also
can bus.
If the problem occurs when request-
ing an exposure, check the Bucky.
027/004 E04 Arm fatal failure A Gantry error was signaled during the
exposure. Occurs after an exposure
when the brightness has been received
and the Generator requests the Gantry
to put the grid into the home position. If
the Gantry does not answer within 3 sec
of the request, this error occurs.
1. Reset Gantry and Generator (i.e.
press off/on on the X-ray Console).
2. Check other Gantry related errors
to determine the route cause. Proba-
ble route causes include the Bucky,
Collimator, and Filter Wheel.
Code Message text Description Recommended actions
