GE Senographe DS

GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
ERR SUB A003 - Gantry Error Messages
Page no. 861 Chapter 9
ERR-SUB-A-003.fm
102/036 HALT LIFT TX CAN BUF-
FER OVERRUN
Possible causes:
• There has been a transmit queue overrun. The
transmit queue between the MCU and the DSP is
full and the message dropped.
• The TP1 connector on the Lift board is closed.
Proceed as follows:
Check whether a jumper exists on the TP1 connector
on the Lift board. In this case you must remove the
jumper from the TP1 connector on the Lift board.
If there is no jumper on the TP1 connector on the Lift
board, the Lift board is faulty. Change the Lift board
then perform a Lift Calibration.
D/R A201
page
1161
CAL A031
page
1687
102/037 HALT LIFT MAILBOX
OVERRUN
The mailbox is overrun. The mailbox queue used in
the inter-task communication in the MCU is full and
the mails are dropped.
The Lift board is faulty. You must change the Lift
board then perform a Lift Calibration.
D/R A201
page
1161
CAL A031
page
1687
102/038 HALT CPU HEARTBEAT
NOT RECEIVED BY
LIFT NODE
There has been a heartbeat failure. The Gantry CPU
did not send periodic "heartbeat" CAN message.
1. Change the Gantry CPU Board (see Job Card D/
R A190 - Gantry CPU Board on page 1131).
2. Perform a Collimator Calibration (see Job Card
CAL A029 - Collimator Format Calibration on
page 1683).
3. Perform a Collimation Check (see Job Card ELE
A028 - Collimation Checks on page 679).
D/R A190
page
1131
CAL A029
page
1683
ELE A028
page 679
102/039 DEBUG
ONLY
HEARTBEAT DIS-
ABLED ON LIFT
NODE
The Gantry CPU tried to disable the "heartbeat"
check of the lift node.
1. Change the Gantry CPU Board (see Job Card D/
R A190 - Gantry CPU Board on page 1131).
2. Perform a Collimator Calibration (see Job Card
CAL A029 - Collimator Format Calibration on
page 1683).
3. Perform a Collimation Check (see Job Card ELE
A028 - Collimation Checks on page 679).
D/R A190
page
1131
CAL A029
page
1683
ELE A028
page 679
102/040 HALT LIFT INVALID PDO
LENGTH
The lift node receives a PDO with an invalid DLC.
Refer to JC DIAG A1110 ROTATION CONTROL
FAILURE on page 952 to fix the problem.
A1016
page 949
Code Category Text in Log File or
on LCD
Possible Cause/Recommended Action Job Card
