GE Senographe DS User Manual

GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card DIAG A1000 - Gantry Diagnostic
Page no. 949 Chapter 9
JC-DIAG-A-1000.fm
FRUs:
2-9 JC DIAG A1015 LIFT CONTROL FAILURE
Diagnostic for:
101/004 error code (CAN code is 0x9002) valid motion error
1. Perform a lift calibration (see Job Card CAL A031 - Lift Calibration on page 1687).
2. If the error persists, inspect the cables listed below. If you find any damage in a cable or connector,
change the cable. If no defect can be seen, change the cables in the following order:
- W213 - POS-BUS 1 cable for Lift to Rotation
- W304A cable for paddle detector
- W304B cable for paddle detector
- W314 Sys Pos Bus cable
- W311 - POS-BUS 2 cable for Bucky board
3. If the error persists, change the Lift Board (see Job Card D/R A201 - Lift Board on page 1161).
4. If the error persists, change the PL 103 CPU Board (see Job Card D/R A190 - Gantry CPU Board on
page 1131).
FRUs:
2-10 JC DIAG A1016 LIFT CONTROL FAILURE
Diagnostic for:
102/040 error code (CAN code is 0x8210) invalid PDO length
• Change the Lift Board (see Job Card D/R A201 - Lift Board on page 1161).
• If the error persists, change the Gantry CPU Board (see Job Card D/R A190 - Gantry CPU Board on
page 1131).
• If changing the CPU solved the problem, put back the original Lift Board (see Job Card D/R A201 -
Lift Board on page 1161).
FRUs:
Lift Board
Gas spring
Motor + encoder with cable
Lift Board
W314 Sys Pos Bus cable
W304A cable for paddle detector
W304B cable for paddle detector
W311 - POS-BUS 2 cable for Bucky board
W213 - POS-BUS 1 cable for Lift to Rotation
Nephtys Gantry CPU
Lift Board
Nephtys Gantry CPU
