GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card DIAG A1000 - Gantry Diagnostic
2-6 JC DIAG A1012 LIFT CONTROL FAILURE
Diagnostic for:
102/013 error code (CAN code is 0x6004) overspeed error
• Check the error logs. If this error occurs at the same time than as error 102/014 "lift under speed",
change the lift gas spring. See Job Card D/R A206A - Lift Gas Spring on page 1183.
• If the problem persists, check the DC level of complementarity outputs: A/A complementary, and B/B
complementary on the encoder connector: Lift Board J9 for W205.
The acceptable levels are 5 VDC and 0 VDC.
(The signal is 4-phase: A/A complementary, and B/B complementary)
• If the DC level is good, change the Lift Board (see Job Card D/R A201 - Lift Board on page 1161).
FRUs:
If the Lift Board or motor unit is changed, recalibration is necessary!
2-7 JC DIAG A1013 LIFT CONTROL FAILURE
Diagnostic for:
102/004 error code (CAN code is 0xxxxx) lift low speed error
102/014 error code (CAN code is 0x6005) lift low speed error
102/024 error code (CAN code is 0xxxxx) uncontrolled lift motion error
• Check the motor cable (between the coil wires, and between the control wires and the ground wires),
then measure the motor coil resistance.
• If the cable is broken, change the motor unit with encoder and cables (see Job Card D/R A205 - Lift
Motor on page 1179).
• If the cable and the motor are good, change the Lift Board (see Job Card D/R A201 - Lift Board on
page 1161).
• If the Lift Board is good change the gas spring for lift compensation (see Job Card D/R A206A - Lift
Gas Spring on page 1183).
FRUs:
2-8 JC DIAG A1014 LIFT POSITION OVERSHOOT
Diagnostic for:
102/030 error code (CAN code is 0x6006) position error
102/031 error code (CAN code is 0x6007) deceleration error
• Change the Lift Board (see Job Card D/R A201 - Lift Board on page 1161).
• If the Lift Board is good, change the gas spring for lift compensation (see Job Card D/R A206A - Lift
Gas Spring on page 1183).
Lift Board
Motor + encoder with cable
Gas spring
Lift Board
Motor + encoder with cable
Gas spring
