Chapter 9 Page no. 904
ERR-SUB-A-003.fm
GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
ERR SUB A003 - Gantry Error Messages
141/021 INHIBIT Coll PDO1 length
error
PDO[i] (for i=1 - 4) length error = it is a standard error
signal. The Gantry CPU sends a command message
which contains a certain number of databytes. In
case the length of the PDO is not adequate, this sig-
nal is produced.
PDO1: change FOV, PDO2: change filter type,
PDO3: lamp on/off, PDO4: change focal spot
Possible causes of error:
• Collimator has received bad data on its node
• Communication conflict/mismatch between system
and collimator
Actions to correct problem:
1. Check the cable connection (W409) between the
collimator and system, then restart system.
2. If the problem persists, change the CPU board
(re-calibrate the collimator afterwards).
3. If the problem persists, contact your OLC.
D/R A190
page
1131
CAL A029
page
1683
141/022 INHIBIT Coll PDO2 length
error
141/023 INHIBIT Coll PDO3 length
error
141/024 INHIBIT Coll PDO4 length
error
142/001 DEBUG
ONLY
Coll 12V lamp power
failure
The power is down for 12 VDC (lamp).
See JC DIAG A1401 LIGHT CENTERING FAILURE
on page 967 to fix the problem.
A1401
page 967
142/003 INHIBIT Coll front blade over-
current
Axis[i] (for i=1 - 5) is protected = the axis is pro-
tected. This is either because the motor current is
over threshold for more than accepted range, or
there is abnormal noise on control board.
Possible reasons for overcurrent:
1. Mechanical resistance is too big
2. Control board failure
3. The frequency of system commands is too fast
See JC DIAG A1406 COLL BLADE OVERCUR-
RENT on page 970 to fix the problem.
A1406
page 970
142/004 INHIBIT Coll left blade over-
current
142/005 INHIBIT Coll rear blade over-
current
142/006 INHIBIT Coll right blade over-
current
142/007 INHIBIT Coll filter overcurrent Like blade overcurrent.
See JC DIAG A1407 COLL FILTER OVERCUR-
RENT on page 970 to fix the problem.
A1407
page 970
Code Category Text in Log File or
on LCD
Possible Cause/Recommended Action Job Card
