GE Senographe DS

GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
ERR SUB A003 - Gantry Error Messages
Page no. 915 Chapter 9
ERR-SUB-A-003.fm
161/038 HALT COMPR NODE NOT
RESPONDING
Possible causes:
• The Compression node did not send the Heartbeat
signal. Between two motions, the compression
node sends a Heartbeat signal every second to
Gantry CPU. If not, the Gantry CPU creates this
error. During lift motion, the compression node
sends an actual value message regularly in addi-
tion to the heartbeat. If not, the Gantry CPU creates
this error.
• The TP1 connector on the Compression board is
closed.
Proceed as follows:
1. Reboot the system from the X-ray Console and
perform a compression motion before a com-
plete Gantry boot.
2. If the problem persists check the error logs. If this
error occurs in conjunction with error 167/004,
there is a possibility that a jumper exists on the
TP1 connector on the Compression board. In this
case you must remove the jumper from the TP1
connector on the Compression board.
3. If the problem persists, change the Compression
Board (Firmware or Hardware problem) and re-
calibrate compression force sensor and com-
pression thickness.
4. If the problem persists, check CAN bus.
D/R A250
page
1323
CAL A048
page
1709
CAL A050
page
1721
161/039 HALT INTERNAL SOFT-
WARE ERROR
The Gantry CPU received an unknown error code
from the lift node.
1. Reboot the system from the X-ray Console.
2. If the problem persists check then check the
debug text into the error log,
- If the error code is 20497, replace both foot-
switches.
- If the error code is 20535, replace the lift poten-
tiometer.
- If the error code is 20545, reboot the system
and if the problem persists with error code 20545
then replace the lift board.
- if the error code is different contact your OLC.
D/R A204
page
1175
D/R A201
page
1161
Code Category Text in Log File or
on LCD
Possible Cause/Recommended Action Job Card
