Chapter 9 Page no. 956
JC-DIAG-A-1000.fm
GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card DIAG A1000 - Gantry Diagnostic
2-25 JC DIAG A1201 KEYPAD FAILURE
Diagnostic for:
120/001 error code (CAN code is 0x9016) lift up pressed
120/002 error code (CAN code is 0x9017) lift up pressed
120/003 error code (CAN code is 0x9018) lift down pressed
120/004 error code (CAN code is 0x9019) lift down pressed
120/005 error code (CAN code is 0x901A) rot left pressed
120/006 error code (CAN code is 0x901B) rot left pressed
120/007 error code (CAN code is 0x901C) rot right pressed
120/008 error code (CAN code is 0x901D) rot right pressed
120/009 error code (CAN code is 0x9020) CC pressed
120/010 error code (CAN code is 0x901E) MLO left pressed
120/011 error code (CAN code is 0x901F) MLO right pressed
122/009 error code (CAN code is 0x5016) lift up error
122/010 error code (CAN code is 0x5017) lift up error
122/011 error code (CAN code is 0x5018) lift down error
122/012 error code (CAN code is 0x5019) lift down error
122/013 error code (CAN code is 0x501A) rot left error
122/014 error code (CAN code is 0x501B) rot left error
122/015 error code (CAN code is 0x501C) rot right error
122/016 error code (CAN code is 0x501D) rot right error
122/017 error code (CAN code is 0x5020) CC error
122/018 error code (CAN code is 0x501E) MLO error
122/019 error code (CAN code is 0x501F) MLO error
• Ensure that nothing is pressing on any keypad button, then reboot the Gantry.
• If the same message appears:
- Check the keypad cable and connections. If the cable is faulty, change it.
- Disconnect the keypad and connect another of the installed keypads in its place, then reboot the
Gantry. If the keypad is found to be faulty, change it.
- Change the Compression Board (see Job Card D/R A250 - Compression Board on page 1323).
FRUs
W305 cable for keypad
Handle keypad PL305
Compr Board
