GE HEALTHCAREDRAFT VOLUSON E8 / VOLUSON E6
D
IRECTION KTD102576, REVISION 7 DRAFT (AUGUST 23, 2012) SERVICE MANUAL
Chapter 4 - Functional Checks 4-31
4-4-12 Erasing DVD/CD
1.) Press the UTILITIES key on the control panel.
2.) In the “Utilities” menu touch SYSTEM SETUP
to invoke the setup desktop on the screen.
3.) On the left side of the screen select CONNECTIVITY
and then click the DRIVES tab.
4.) Click the ERASE CD
button to displays the “Erase DVD/CD” window as shown in Figure 4-21.
5.) Select the “Erase Mode” and click the [OK] button to start the process.
6.) When erasing is finished, select EXIT
to return to the Scan Mode.
Figure 4-20 System Setup - Connectivity - DRIVES page
!! NOTICE:
It is highly recommended to use the complete erase mode, to avoid problems with the CD+(R)W!
When using a DVD+R/RW, the complete erase mode is not possible.
Figure 4-21 Erase DVD/CD Window
