GE HEALTHCARERAFT VOLUSON E8 / VOLUSON E6
D
IRECTION KTD102576, REVISION 7 DRAFT (AUGUST 23, 2012) SERVICE MANUAL
5-50 Section 5-6 - Top Console (User Interface)
5-6-1 RTH - Distribution Board USB-Hub
Function of the Distribution Board Hub (RTH):
• USB2.0 Interface, Board is connected to PC via USB cable
• 7 port USB2.0 Hub
• 4 USB Ports for external use
• 1 USB to IDE Converter for DVD Drive
• 2 USB Ports not used
• Power distribution for Monitor
• Feed through for DC-Power for the DVD Drive and Fan
