GE HEALTHCAREDRAFT VOLUSON E8 / VOLUSON E6
D
IRECTION KTD102576, REVISION 7 DRAFT (AUGUST 23, 2012) SERVICE MANUAL
Chapter 5 - Components and Functions (Theory) 5-49
Section 5-6 Top Console (User Interface) (cont’d)
Figure 5-25 User Interface
Start Key
Unlock console
Micro
Controller
USB 2.0
Hub
+12V
+5V (Stand by)
Start Key
GEL_EN
Brake_EN
Lifter Ctrl.
PWR_OK
USB 2.0
25 Pol Sub D
DIN Keyboard
USB/VGA Converter
10,4" Display & Touchpanel
From PC
from/to RTT
DC/DC
Converter
Trackball
+12V
+3,3V (Microcontroller)
+5V (Back Lighting)
