GE HEALTHCAREDRAFT VOLUSON E8 / VOLUSON E6
D
IRECTION KTD102576, REVISION 7 DRAFT (AUGUST 23, 2012) SERVICE MANUAL
Chapter 5 - Components and Functions (Theory) 5-55
Table 5-3 Voluson E8 / Voluson E6 - key codes
key code Description Voluson E8 / Voluson E6 - Functionality X X X
1
Power/Standby ON/OFF
ON/OFF Standby button of the system
2
UI Level Adjustment
Height Adjustment (Elevation) of the Control Console (User Interface)
3
Utilities
call-up of the utilities menu
4
Patient Data (PID)
call-up of the patient data entry menu and/or patient archive
5
Probe
call-up of the probe program menu
6
Review
call-up of exam review mode and/or patient archive
7
End Exam
Patient and measurement data are stored in the “Data manager”
8
Paddle (Toggle) switch
UP - Toggle switch (function depends on currently selected mode)
9
Paddle (Toggle) switch
DOWN - Toggle switch (function depends on currently selected mode)
10
Paddle (Toggle) switch
UP - Toggle switch (function depends on currently selected mode)
11
Paddle (Toggle) switch
DOWN - Toggle switch (function depends on currently selected mode)
12
DVD / VCR
also used to lower control console (in combination with 2 other keys)
13
BT09: none / BT10/12/13: Elasto
BT09: no functionality / BT10/BT12/BT13: invokes Elastography function
14
Acquisition Mode TD
invokes TD-Mode (Tissue Doppler Mode)
15
Acquisition Mode Contrast
invokes Contrast Imaging function
16
Acquisition Mode XTD
invokes XTD-View (Extended View) function
17
Acquisition Mode BF
invokes B-Flow function
18
Acquisition Mode CW
invokes CW-Mode (Continuous Wave Doppler)
19
Report
call-up of the Patient report page
20
Bodymark
Bodymark display - to enter Bodymark symbols
21
HI
(Coded) Harmonic Imaging
22
Dual Format (V)
Dual-Screen format (vertical distribution)
23
Quad Format
Quad-Screen format
24
Single Format
Single-Screen format
25
Auto (OTO)
Automatic Optimization
26
ABC (Text)
Image Annotation - to write onto the screen
27
Clear
to clear graphics, measurements and annotations on the screen
28
Caliper
Generic Measurements
29
Calc
Calculation (tables)
30
Acquisition Mode 4D
invokes Real Time 4D Mode (continuos volume sweep)
31
Acquisition Mode 3D
invokes 3D Volume Mode
32
Depth (Toggle) switch
Penetration Depth UP - Toggle switch function
33
Depth (Toggle) switch
Penetration Depth DOWN - Toggle switch function
34
Focus Depth (Toggle) switch
Focus Depth UP - Toggle switch function
35
Focus Depth (Toggle) switch
Focus Depth DOWN - Toggle switch function
36
Trackball pointer
displays a pointer (arrow or hand shaped cursor)
37
P2
programmable key
38
P4
programmable key
39
Exit
Exit current menu
40
P1
programmable key
41
P3
programmable key
42
Trackball Mode switch
function depends on currently selected mode
43
Trackball Mode switch
function depends on currently selected mode
44
Trackball Mode switch
function depends on currently selected mode
