GE HEALTHCARERAFT VOLUSON E8 / VOLUSON E6
D
IRECTION KTD102576, REVISION 7 DRAFT (AUGUST 23, 2012) SERVICE MANUAL
5-56 Section 5-6 - Top Console (User Interface)
45
Freeze
Read/Write (Freeze/Run)
46
Encoder 1
function depends on currently selected mode
47
Encoder 2
function depends on currently selected mode
48
Encoder 3
function depends on currently selected mode
49
Encoder PW-Mode
PW-Mode (Pulsed Wave Doppler)
50
Encoder M-Mode
M-Mode (Motion Mode)
51
Encoder PD-Mode
PD-Mode (Power Doppler) and HD-Mode (Bi-Directional Angio)
52
Encoder C-Mode
C-Mode (Color Flow Mode)
53
Encoder 2D-Mode
2D-Mode (B-Mode)
54
label illuminated: Power (Probe)
Acoustic Output (Ultrasound emission of a probe)
55
label illuminated: Power (Speaker)
Acoustic Output (Speakers)
56
label illuminated: HR-Zoom
image magnification of selected image area
57
label illuminated: Pan Zoom
image magnification of complete image
58
label illuminated: X
Volume Mode icon (rotation about X-axis)
59
label illuminated: Y
Volume Mode icon (rotation about Y-axis)
60
label illuminated: Z
Volume Mode icon (rotation about Z-axis)
61
label illuminated:
Volume Mode icon (movement along Z-axis)
62
Slider 1
TGC Slider Control
63
Slider 2
TGC Slider Control
64
Slider 3
TGC Slider Control
65
Slider 4
TGC Slider Control
66
Slider 5
TGC Slider Control
67
Slider 6
TGC Slider Control
68
Slider 7
TGC Slider Control
69
Slider 8
TGC Slider Control
70
UI Brake
Rotation/Translation of the Control Console (User Interface)
71
Trackball button
left trackball key
72
Trackball button
upper trackball key
73
Trackball button
right trackball key
Table 5-3 Voluson E8 / Voluson E6 - key codes
key code Description Voluson E8 / Voluson E6 - Functionality X X X
