GE HEALTHCARERAFT VOLUSON E8 / VOLUSON E6
D
IRECTION KTD102576, REVISION 7 DRAFT (AUGUST 23, 2012) SERVICE MANUAL
10-8 Section 10-5 - System Maintenance
10-5-2-2 Peripheral/Option Checks
If any peripherals or options are not part of the system configuration, the check can be omitted.
Refer to Table 3-7, “Approved Peripherals,” on page 3-54 for a list of approved peripherals.
10-5-2-3 Mains Cable Inspection
10-5-2-4 Optional Diagnostic Checks
Optionally you can access the diagnostic software as described in Chapters 5 or 7.
View the error logs and run desired diagnostics.
Table 10-5 Approved Peripheral/Hardware Option Functional Checks
Step Item Description
1 B/W Printer
Verify hardcopy output of the B/W video page printer. Clean heads and covers if necessary.
2 Color Printer
Verify hardcopy output of the Color video page printer. Clean heads and covers if necessary.
3
Color Deskjet
(Bluetooth) Printer
Verify hardcopy output of the Deskjet (Bluetooth) printer. Clean heads and covers if necessary.
4 VCR
Verify record/playback capabilities of the VCR. Clean heads and covers if necessary.
5 DVD recorder
Verify record capabilities of the DVD recorder. Clean heads and covers if necessary.
6 DICOM
Verify that DICOM is functioning properly. Send an image to a DICOM device.
7 Footswitch
Verify that the footswitch is functioning as programed. Clean as necessary.
8DVD-Drive
Verify that the DVD-drive reads/writes properly
(export/recall image in Image Management System = Archive)
9ECG
Verify basic operation with customer.
Table 10-6 Mains Cable Inspection
Step Item Description
1 Unplug Cord
Disconnect the mains cable from the wall and system.
2 Inspect
Inspect it and its connectors for damage of any kind.
3Verify
Verify that the LINE, NEUTRAL and GROUND wires are properly attached to the terminals, and that
no strands may cause a short circuit.
4 Verify
Inlet connector retainer is functional.
