takesthevaluepresetviakeypadorRS485orBUS,beforetoassignananaloginput.
Exceptionarethe“PAD”parameters,wherethelastvalueontheanaloginputisstored
whenAninXXtarget=notassignedisexecuted.
Input XX type Selectionofinputtype(voltageorcurrentinput)
 JumpersontheregulatorcardoftheTPD32-EVshouldbettedorremovedaccording
totheinputsignalused.Theinputsofthedevicearefactorysetforvoltagesignls.
Analog Input Input Signal
-10 V ... + 10 V
0 - 10 V
0 - 20 mA
4 - 20 mA
Analoginput1 S9=OFF S9=ON
Analoginput2 S10=OFF S10=ON
Analoginput3 S11=OFF S11=ON
GD6185g
 ON Jumpertted
 OFF Jumpernottted
10V...+10V Avoltageofmax±10Visconnectedtotheanaloginputconcerned.
Ifthesignalisusedasareferencevalue,apolarityreversalcan
beusedtoreversetherotationdirectionofthedrive(onlywith
TPD32-EV...4B converters).TheTPD32-EV...2Bconverters
acceptasspeedreferenceonlypositivereferences.Negativerefer-
encesarenotacceptedandthedrivedoesnotstart.
0-10V,0-20mA Avoltageofmax.10Voracurrentsignalof0...20mAis
connectedtotheanaloginputconcerned.Thesignalmustbe
positive.IfthesignalisusedasareferencevalueforTPD32-
EV...4Bconverters,therotationdirectioncanbereversedvia
theInput XX sign +andInput XX sign -parameters.
4-20mA Acurrentsignalof4...20mAisconnectedtotheanaloginput
concerned.Thesignalmustbepositive.Ifthesignalisused
asareferencevalueforTPD32-EV...4Bconverters,thedrive
rotationdirectioncanbereversedviatheInput XX sign +
andInput XX sign -parameters.
Input XX sign Selectionofrotationdirectionwhenoperatedviatheserialinterfaceorbusforthetet-
raquadrantTPD32-EV...4Bconverters.
Input XX sign + Selectionof“Clockwise”rotationwhenoperatedviatheterminalstripfortheTPD32-
EV...4Bconverters,whenthereferencevalueisonlygivenwithonepolarity.
 High Clockwiseselected
 Low Clockwisenotselected
Input XX sign - Selectionof“Counter-clockwise”rotationwhenoperatedviatheterminalstripforthe
TPD32-EV...4Bconverters,whenthereferencevalueisonlygivenwithonepolarity.
 High Counterclockwiseselected
 Low Counterclockwisenotselected
 IfbothInput XX sign+andInput XX sign-are0or1thereferencevalueiszero.
Scale input XX Scalingofthecorrespondinganaloginput
 1)
 Withascalingfactorof1andaTune value inp XX=1,10Vor20mAonthe
inputcorrespondtotheSpeed base value.
 2)
 Withascalingfactorof1andaTune value inp XX=1,10Vor20mAonthe
inputcorrespondtomaxpossiblecurrent.
 3)
 Withascalingfactorof1,10Vor20mAintheinputcorrespondtothePadvalueof2047.
