gefran TPD32-EV-...-4B User Manual

—————— TPD32-EV ——————
234
Up
Down
Mpot output mon
1s 1s
1rpm
1rpm
Mode:Fine
Mpot mode Ramp behaviour
Behaviour of the Motor potentiometer function with the
Stop or FastStop command present with the Control
mode = Ramp parameter.
0 Ramp Last val
1 Ramp Follow
2 Fine Last val
3 Fine Follow
Forne-tuningoftheMotorpotentiometeroutputvaluetherecommendedsettingsareMpot Mode = Fine&Follow
or Fine&Last Val.Eachtimetheyarepressedfor1second,thespeedincreasesby1rpm.Foranimmediate
effectonmotorspeed,theAccelerationtimeandDecelerationtimeparametersshouldbesettoshorttimes.
PowerOn Cfg CongurationofthemotorpotatpoweronwhenCong2isselected.
 ThisparameterisneededtoconguretheoutputvalueoftheMotorpotentiometerat
drivestart-up.
LastPoweroff WhensettoLast power off,themotorpotentiometeroutput
startsfromthelastreferencethatwassetbeforethedrivewas
switchedoff.
 Zero WhensettoZerothemotorpotentiometeroutputstartsfrom
avalueof0.
 LowerLimit WhensettoLower limittheoutputofthemotorpotentiometer
startsfromthevalueofthelowerlimitsetintheMpot bottom
limit parameter.
 UpperLimit WhensettoUpper limittheoutputofthemotorpotentiometer
startsfromthevalueoftheupperlimitsetintheMpot top
limit parameter.
Reset Cfg CongurationoftheMotorpot reset whenCong2isselected.
 ThisparametercanbeusedtoconguretheresetoftheMotorpotentiometerfunction,
i.e.tocongurethevalueatwhichtheMotorpotentiometerinputandoutputareset
whentheresetcommandisenabled.
 TheresetcommandhaspriorityovertheUpcommandandtheDown command.
 TheUpandDown commandsareenabledagainwhentheresetcommandisdisabled.
None WhensettoNone,nosettingisexecuted
 InpZero setsinput=0i.e.atemporaryreferencesettingisperformed
andtheprevious referencevalueis maintained.The output
oftheMotorpotentiometerfunctionvarieswiththesetramp
times.Thepreviousreferencevalueisrestoredwhenthereset
commandisremoved.
 InpLowLimit setsInp=lowlimi.e.atemporaryreferencesettingisperformed
