—————— Instruction manual ——————
87
Table 4.9.1.1: Fa, External input side fuses
TPD32 EV
Standard sizes
Quantity
Standard American
Type Code Type Code
TPD32-EV-.../...-20-..-A 3 Z14gR20 F4M07 A70P25 S7G51
TPD32-EV-.../...-40-..-A 3 Z22gR50 F4M15 A70P40 S7G52
TPD32-EV-.../...-70-..-A 3 Z22gR63 F4M17 A70P80 S7G54
TPD32-EV-.../...-110-..-A 3 S00C+/üf1/80/100A/660V F4EAG A70P100 S7G55
TPD32-EV-.../...-140-..-A 3 S00C+/üf1/80/125A/660V F4EAJ A70P150 S7G56
TPD32-EV-.../...-185-..-A 3 S00üF1/80/200A/660V F4G23 A70P175 S7G57
TPD32-EV-.../...-280-..-B 3 S1üF1/110/250A/660V F4G28 A70P300 S7G60
TPD32-EV-.../...-350-..-B 3 S1üF1/110/315A/660V F4G30 A70P350 S7G61
TPD32-EV-.../...-420-..-B 3 S1üF1/110/400A/660V F4G34 A70P400 S7G62
TPD32-EV-.../...-500-..-B 3 S1üF1/110/500A/660V F4E30 A70P500 S7G63
TPD32-EV-.../...-650-..-B 3 S1üF1/110/630A/660V F4E31 A70P600 S7G65
TPD32 EV
American sizes
Quantity
American
Type Code
TPD32 EV-...-.../...-17-..-A-NA 3 A70P25 S7G51
TPD32 EV-...-.../...-35-..-A-NA 3 A70P40 S7G52
TPD32 EV-...-.../...-56-..-A-NA 3 A70P80 S7G54
TPD32 EV-...-.../...-88-..-A-NA 3 A70P100 S7G55
TPD32 EV-...-.../...-112-..-A-NA 3 A70P150 S7G56
TPD32 EV-...-.../...-148-..-A-NA 3 A70P175 S7G57
TPD32 EV-...-.../...-224-..-B-NA 3 A70P300 S7G60
TPD32 EV-...-.../...-280-..-B-NA 3 A70P350 S7G61
TPD32 EV-...-.../...-336-..-B-NA 3 A70P400 S7G62
TPD32 EV-...-.../...-400-..-B-NA 3 A70P500 S7G63
TPD32 EV-...-.../...-450-..-B-NA 3 A70P600 S7G65
Table 4.9.1.2:
Fb, External fuses for the armature circuit
TPD32 EV
Standard sizes
Quantity
Standard American
Type Code Type Code
TPD32-EV-500/...-20-4B-A 2 Z14gR20 F4M07 A70P25 S7G51
TPD32-EV-500/...-40-4B-A 2 Z22gR63 F4M17 A70P80 S7G54
TPD32-EV-500/...-70-4B-A 2 S00C+/üf1/80/100A/660V F4EAG A70P100 S7G55
TPD32-EV-500/...-110-4B-A 2 S00C+/üf1/80/125A/660V F4EAJ A70P150 S7G56
TPD32-EV-500/...-140-4B-A 2 S00C+/üf1/80/160A/660V F4EAL A70P175 S7G57
TPD32-EV-500/...-185-4B-A 2 S00üF1/80/200A/660V F4G23 A70P200 S7G58
TPD32-EV-500/...-280-4B-B 2 S1üF1/110/315A/660V F4G30 A70P350 S7G61
TPD32-EV-500/...-350-4B-B 2 S2üF1/110/400A/660V F4G34 A70P400 S7G62
TPD32-EV-500/...-420-4B-B 2 S2üF1/110/500A/660V F4E30 A70P500 S7G63
TPD32-EV-500/...-500-4B-B 2 S2üF1/110/630A/660V F4E31 A70P600 S7G65
TPD32-EV-500/...-650-4B-B 2 S2üF1/110/710A/660V F4G85 A70P700 S7G67
TPD32-EV-575/...-280-4B-B 2 S2üf01/110/315A/1000V - A100P350-4 -
TPD32-EV-575/...-350-4B-B 2 S2üf01/110/400A/1000V A100P400-4
TPD32-EV-575/...-420-4B-B 2 S2üf01/110/500A/1000V A100P500-4
TPD32-EV-575/...-500-4B-B 2 S3üf01/110/630A/1000V S85C4 A100P600-4
TPD32-EV-575/...-650-4B-B 2 S3üf01/110/710A/1000V S85C5 A100P800-4
TPD32 EV
American sizes
Quantity
American
Type Code
TPD32 EV-500/...-17-4B-A-NA 2 A70P25 S7G51
TPD32 EV-500/...-35-4B-A-NA 2 A70P40 S7G52
TPD32 EV-500/...-56-4B-A-NA 2 A70P80 S7G54
TPD32 EV-500/...-88-4B-A-NA 2 A70P100 S7G55
TPD32 EV-500/...-112-4B-A-NA 2 A70P150 S7G56
TPD32 EV-500/...-148-4B-A-NA 2 A70P175 S7G57
TPD32 EV-500/...-224-4B-B-NA 2 A70P300 S7G60
TPD32 EV-500/...-280-4B-B-NA 2 A70P350 S7G61
TPD32 EV-500/...-336-4B-B-NA 2 A70P400 S7G62
TPD32 EV-500/...-400-4B-B-NA 2 A70P500 S7G63
TPD32 EV-500/...-450-4B-B-NA 2 A70P600 S7G65
