TPD32 EV
American sizes
Quantity
American
Type Code
TPD32 EV-575/...-224-4B-B-NA 2 A100P300-4
TPD32 EV-575/...-280-4B-B-NA 2 A100P350-4
TPD32 EV-575/...-336-4B-B-NA 2 A100P400-4
TPD32 EV-575/...-400-4B-B-NA 2 A100P500-4
TPD32 EV-575/...-450-4B-B-NA 2 A100P600-4
Note: Necessaryonlyforthefourquadrantfunctioning.
Table 4.9.1.3:
Fc, Internal input side fuses
TPD32 EV
Standard sizes
Quantity
Standard American
Type Code Type Code
TPD32 EV-500/600-770-2B-C 3 G2MUF02 800A 660V S826B 170M 5464 800A 660V S7792
TPD32 EV-500/600-1000-2B-C 3 170M 5466 1000A 660V S827B 170M 5466 1000A 660V S827B
TPD32-EV-500/600-1400-2B-D 6 170M 6263 900A 690V S86C1 170M 6263 900A 690V S86C1
TPD32-EV-500/600-1600-2B-D 6 170M 6265 1100A 690V S86C2 170M 6265 1100A 690V S86C2
TPD32-EV-500/600-2000-2B-D 6 170M 6267 1400A 690V S85C2 170M 6267 1400A 690V S85C2
TPD32-EV-500/600-2400-2B-D 12 170M 6263 900A 690V S86C1 170M 6263 900A 690V S86C1
TPD32 EV-500/600-1200-2B-E 6 170M 5464 800A 660V S7792 170M 5464 800A 660V S7792
TPD32 EV-500/600-1500-2B-E 6 170M 6464 1000A 660V S7799 170M 6464 1000A 660V S7799
TPD32 EV-500/600-1800-2B-E 6 170M 6466 1250A 660V S7802 170M 6466 1250A 660V S7802
TPD32 EV-500/600-2000-2B-E 6 170M 6466 1250A 660V S7802 170M 6466 1250A 660V S7802
TPD32 EV-500/600-2400-2B-E 6 170M 6467 1400A 660V S7803 170M 6467 1400A 660V S7803
TPD32 EV-500/600-2700-2B-E 12 170M 6462 800A 660V S7797 170M 6462 800A 660V S7797
TPD32 EV-500/600-2900-2B-E 12 170M 6463 900A 660V S7798 170M 6463 900A 660V S7798
TPD32 EV-500/600-3300-2B-E 12 170M 6466 1250A 660V S7802 170M 6466 1250A 660V S7802
TPD32-EV-575/680-700-2B-C 3 170M 5463 700A 690V S7791 170M 5463 700A 690V S7791
TPD32-EV-575/680-1000-2B-C 3 170M 5466 1000A 690V S827B 170M 5466 1000A 690V S827B
TPD32-EV-575/680-1300-2B-D 6 170M 6263 900A 690V S86C1 170M 6263 900A 690V S86C1
TPD32-EV-575/680-1600-2B-D 6 170M 6265 1100A 690V S86C2 170M 6265 1100A 690V S86C2
TPD32-EV-575/680-2000-2B-D 6 170M 6267 1400A 690V S85C2 170M 6267 1400A 690V S85C2
TPD32-EV-575/680-2300-2B-D 12 170M 6263 900A 690V S86C1 170M 6263 900A 690V S86C1
TPD32-EV-690/810-560-2B-C 3 170M 5461 550A 690V S85C11 170M 5461 550A 690V S85C11
TPD32-EV-690/810-700-2B-C 3 170M 5463 700A 690V S7791 170M 5463 700A 690V S7791
TPD32-EV-690/810-900-2B-C 3 170M 5465 900A 690V S7793 170M 5465 900A 690V S7793
TPD32-EV-690/810-1300-2B-D 6 170M 6263 900A 690V S86C1 170M 6263 900A 690V S86C1
TPD32-EV-690/810-1600-2B-D 6 170M 6265 1100A 690V S86C2 170M 6265 1100A 690V S86C2
TPD32-EV-690/810-1900-2B-D 6 170M 6267 1400A 690V S85C2 170M 6267 1400A 690V S85C2
TPD32-EV-690/810-2100-2B-D 12 170M 6262 800A 690V S85C3 170M 6262 800A 690V S85C3
TPD32 EV-690/810-1010-2B-E 6 170M 5463 700A 660V S7791 170M 5463 700A 660V S7791
TPD32 EV-690/810-1400-2B-E 6 170M 6463 900A 660V S7798 170M 6463 900A 660V S7798
TPD32 EV-690/810-1700-2B-E 6 170M 6465 1100A 660V S7801 170M 6465 1100A 660V S7801
TPD32 EV-690/810-2000-2B-E 6 170M 6466 1250A 660V S7802 170M 6466 1250A 660V S7802
TPD32 EV-690/810-2400-2B-E 12 170M 6461 700A 660V S7796 170M 6461 700A 660V S7796
TPD32 EV-690/810-2700-2B-E 12 170M 6462 800A 660V S7797 170M 6462 800A 660V S7797
TPD32 EV-690/810-3300-2B-E 12 170M 6466 1250A 660V S7802 170M 6466 1250A 660V S7802
TPD32 EV-500/520-770-4B-C 6 170M 5462 630A 660V S825B 170M 5462 630A 660V S825B
TPD32 EV-500/520-1050-4B-C 6 G2MUF02 800A 660V S826B 170M 5464 800A 660V S7792
TPD32-EV-500/520-1400-4B-D 6 170M 6263 900A 690V S86C1 170M 6263 900A 690V S86C1
TPD32-EV-500/520-1600-4B-D 6 170M 6265 1100A 690V S86C2 170M 6265 1100A 690V S86C2
TPD32-EV-500/520-2000-4B-D 6 170M 6267 1400A 690V S85C2 170M 6267 1400A 690V S85C2
TPD32-EV-500/520-2400-4B-D 12 170M 6263 900A 690V S86C1 170M 6263 900A 690V S86C1
TPD32 EV-500/520-1500-4B-E 6 170M 5465 900A 660V S7793 170M 5465 900A 660V S7793
TPD32 EV-500/520-1700-4B-E 6 170M 6466 1250A 660V S7802 170M 6466 1250A 660V S7802
TPD32 EV-500/520-2000-4B-E 6 170M 6466 1250A 660V S7802 170M 6466 1250A 660V S7802
