10
Comment Controls/Keys and Connections
No Description Meaning
1 Microphone hole internal microphone
2 Keypad Record control and play-back control of the
current dictation (see Fig. 4, 23-26)
3 Display buttons Labeling in the display
4 Up-Down-buttons Navigation
5 On/Off button Digta On- and Off switching
6 Battery compartment For rechargeable 962- or AAA-batteries
7 Unlocking button Unlocking button for the battery compartment
8 Menu button Digta menu access
9 OK button Key button
End recording of dictation and play it back
(only if activated in the Digta Configurator)
10 New button Create a new dictation
End recording and create a new dictation
11 Left-right-buttons Navigation
12 Display Operational status indicator and indicator of
the adjustable menu functions (for details see
Fig. 5)
13 Lower function button Press button briefly: Help for the current On-/•
Off-setting of functions
Long pressing: Keylock On/Off switch•
14 Upper function button Press button briefly: Display illumination •
On-/Off
Press button long: EOL* (if activated)•
15 Battery compartment Battery compartment for batteries or recharge-
able batteries*
No Description Meaning
16 Memory card* Memory medium for recorded dictations
17 Recording LED Multicolored LED lights up during recording,
blinks regularly during recording pause
red = overwrite/append•
orange = insert•
green = play-back in USB-audio mode•
yellow = USB-connection/data transmission•
18 Microphone socket Connection for external extra microphone
19 Card slot For memory card
20 Earphone jack Connection for earphone or headphone
21 Contact strip Docking station* connection
22 USB-connection Interface for PC and Grundig power supply
23
g REC button
Control of the current dictation‘s recording:
Start recording, record pause and continue the
recording
Only for devices with speech recognition*:
Keep pressing: Activates speech recognition •
for input of numbers and letters
24
i REW button
Rewind the dictation
End dictation via short backspace and auto-
matic play-back
25
h FF button
Forward dictation (fast forward)
26
e STOP / f PLAY
button
End recording of the dictation
Play-back dictation and stop play-back
27 Clock Time in hours and minutes
28 Voice Activation Speech activation On/Off
