Overview
18
2.4.3 List Sweep
Points
There is a maximum of 10 points.
Sweep parameters
Test frequency, test voltage, test current.
Comparator function of list sweep
The comparator function enables you to set one pair of
lower and upper limits for each measurement point.
You can select from:
Judge with the first sweep parameter/Judge with the
second parameter/Not used for each pair of limits.
2.5 Measurement Assistance Functions
2.5.1 Files
Up to 10 setup conditions can be written to/read from
the built-in non-volatile memory.
2.5.2 Key Lock
The front panel keys can be locked.
2.5.3 RS‐232
Complies with SCPI.
2.6 Options
2.6.1 USB host port
Universal serial bus jack, type-A (4 contact positions,
contact 1 is on your left); female; for connection to USB
memory devices only.
USB disk type: Flash disk only.
Format: FAT / FAT32 / exFAT.
Max memory size: 128GB.
